Optimal fuzzy iterative learning control based on artificial bee colony for vibration control of piezoelectric smart structures
Liang Bai^{1} , YunWen Feng^{2} , Ning Li^{3} , XiaoFeng Xue^{4}
^{1, 2, 4}School of Aeronautics, Northwestern Polytechnical University, Western Youyi Street 127, 710072, Xi’an, P. R. China
^{3}College of Sciences, Northeastern University, 110819, Shenyang, P. R. China
^{2}Corresponding author
Journal of Vibroengineering, Vol. 21, Issue 1, 2019, p. 111132.
https://doi.org/10.21595/jve.2018.19698
Received 1 February 2018; received in revised form 8 May 2018; accepted 24 May 2018; published 15 February 2019
JVE Conferences
Combining Ptype iterative learning (IL) control, fuzzy logic control and artificial bee colony (ABC) algorithm, a new optimal fuzzy IL controller is designed for active vibration control of piezoelectric smart structures. In order to accelerate the learning speed of feedback gain, the fuzzy logic controller is integrated into the ANSYS finite element (FE) models by using APDL (ANSYS Parameter Design Language) approach to adjust adaptively the learning gain of Ptype IL control. For improving the performance and robustness of the fuzzy logic controller as well as diminishing human intervention in the operation process, ABC algorithm is used to automatically identify the optimal configurations for values in fuzzy query table, fuzzification parameters and defuzzification parameters, and the main program of ABC algorithm is operated in MATLAB. The active vibration equations are driven from the FE equations for the dynamic response of a linear elastic piezoelectric smart structure. Considering the vibrations generated by various external disturbances, the optimal fuzzy IL controller is numerically investigated for a clamped piezoelectric smart plate. Results demonstrate that the proposed control approach makes the feedback gain has a fast learning speed and performs excellent in vibration suppression. This is demonstrated in the results by comparing the new control approach with the Ptype IL control.
Keywords: Ptype IL control, fuzzy logic control, artificial bee colony algorithm, active vibration control, piezoelectric smart structure.
1. Introduction
As an intelligent control strategy, iterative learning (IL) control has a simple controller structure and doesn’t require accurate system model. According to fully utilizing the past control experience, it can improve the current control performance of the system by operating repetitively over a fixed time interval [1]. In 1978, IL control was first proposed by Uchiyama in Japanese [2], which did not get much attention. After one critical report published by Arimoto in English [3], IL control had a significant progress in both theory and application [4, 5]. In many cases, it is essential to apply this algorithm to find the system inputs that make the system outputs close possible to the desired outputs, such as hysteresis compensation in a piezoelectric actuator [6], achievement of the extreme precision motion tracking for the control system [7], state estimation on repetitive process systems [5], pointtopoint motion control of robotic arm [8]. However, few papers can be found about the applications of IL control for active vibration control of piezoelectric smart structures. Zhu et al. [9] and Tavakolpour et al. [10] firstly applied Ptype IL control to vibration attenuation of piezoelectric smart structures, and the efficiency of Ptype IL controller had been proven in their studies. In addition, Fadil et al. [11] combined Ptype IL control and PID control to design a new intelligent PID controller for vibration suppression of the piezoelectric smart cantilever beam, in which the Ptype IL control is applied to tune the parameters of the PID controller.
In the studies above, although Ptype IL controllers can effectively attenuate the structural vibrations at some excitation frequencies, the performances of controllers for vibration suppression are still not obvious when the piezoelectric smart structure is excited by its first natural frequency. Besides, control effectiveness of actuators is effective at the locations of sensors, and they are not able to compensate the unwanted vibrations effectively at other locations [12]. In Ptype IL control, thousands of iterations are needed for achieving the satisfying control precision, which leads to learning speed of feedback gain slow [10, 13]. Moreover, unreasonable selections of learning gains may directly cause control spillover or even system instability, which makes the reduction of system robustness [14].
Due to the ability to deal with nonlinearities, uncertainties and imprecision, fuzzy logic has been successfully employed by several research groups for different controller design [1517]. Without exact mathematical model of the structure and certain loading conditions, fuzzy logic controller can be designed in a quite simple way. In order to speed up the learning speed of feedback gain, the learning gain of Ptype IL control is set up by fuzzy logic controller in this paper. However, the effectiveness of fuzzy logic controller depends substantially on appropriate configurations of the membership functions, selections of fuzzy rules and proper operations of the fuzzification and defuzzification, which are all based on the knowledge and experience of researchers and problems being considered [18]. Different optimization technique such as genetic algorithm (GA) [19], ant colony optimization (ACO) [20], and particle swarm optimization (PSO) [2123] have widely been used to find optimum controller parameters for improving the performance of dynamic systems. Another notable optimization algorithm currently being employed is the artificial bee colony, and the main reason of using this algorithm is due to its triple search capability which forages the local and global search space for the optimum solution. The comparative investigations of ABC optimization technique are carried out against GA, ACO and PSO, ABC searching is able to find a better optimum solution [24], the similar performance is exhibited by the PSO technique as well [2426]. However, ABC algorithm possesses a higher speed in comparison with PSO [25, 26]. For improving the performance of the fuzzy logic controller, enhancing the robustness of the controller and diminishing human intervention in the operation process, some control approaches were proposed by combining fuzzy logic control and artificial bee colony (ABC) algorithm [2729]. In these studies, the ABC searching is used to simultaneously autotune the parameters of membership functions and fuzzy rules. However, few studies report that ABC algorithm is applied to optimize fuzzification parameters and defuzzification parameters.
Vibration control of structures such as plates and shells always bring a challenge in aerospace fields because of the complexity and density of the vibration modes. The strategy that discrete piezoelectric actuatorsensor pairs are glued on both surfaces of the plate realizes low weight and effective control for structural vibration [30]. The plate integrated piezoelectric actuatorsensor pairs thus becomes a multiinputmultioutput (MIMO) system. If an actuator fails to perform as expected, the performance of its neighboring actuators will be affected negatively. In this system, the mutual effect among all actuators exists in the whole process of active vibration control, and this kind of mutual effect is always uncertain information. The uncertainty caused by mutual effect brings a great challenge to choose the safe ranges of all the input and output variables, so that the values of fuzzification parameters and defuzzification parameters are difficult to be selected. In this paper, the optimal configurations of the fuzzy logic controller for fuzzification parameters and defuzzification parameters are found based on ABC algorithm. In order to avoid complicated fuzzy inference process and reduce time consumption, a fuzzy query table is established. The values of fuzzy output variable can be chosen directly from the fuzzy query table in the process of active vibration control, and the optimal values in the fuzzy query table are also searched by ABC algorithm. It is the way in which all actuators can affect each other positively so that the optimum control effectiveness can be achieved.
To design a system of piezoelectric smart structure for active vibration control, both control strategy and model of smart structures integrated piezoelectric materials are necessary to be considered. The finite element (FE) method is a widely accepted and powerful tool to deal with the piezoelectric smart structures. Some kinds of efficient and accurate electromechanically coupled dynamic FEs of smart structures have already been developed [3133]. Among commercial FE analysis codes, ANSYS has the ability to model smart structures with piezoelectric materials, and H Karagülle et al. [34] successfully integrated the vibration control actions into the ANSYS modeling, and the solution is achieved as well.
By fusing Ptype IL control, fuzzy logic control and ABC algorithm, a new optimal fuzzy IL control approach is developed for vibration control of piezoelectric smart structures in this paper. For accelerating the learning speed of feedback gain, the learning gain can be adjusted adaptively by fuzzy logic controller. In order to improve the performance and robustness of the fuzzy logic controller, the ABC searching is used to find the optimal parameters of the fuzzy logic controller. The Ptype IL controller and the fuzzy logic controller included the fuzzy query table are integrated into the ANSYS FE model by using ANSYS Parameter Design Language (APDL) approach, and ABC algorithm is realized in MATLAB. The control strategy is numerically investigated for a clamped piezoelectric smart plate under various external disturbances, and the results are illustrated and extensively discussed at the end.
The rest of this paper is organized as follows. In Section 2, based on the FE model of a piezoelectric smart structure, a state space model of the linear system is developed for control law design. The Ptype IL control is described for using vibration control of piezoelectric smart structures. Section 3 introduces the designing of the optimal fuzzy IL control in detail. In Section 4, numerical simulations are presented to demonstrate the usefulness and advantages of the proposed control approach. The last section concludes the paper.
2. Modeling and Ptype IL control
2.1. Dynamic finite element model
The linear electromechanically coupled dynamic FE equation of smart structures can be written as [35]:
where, $\mathbf{u}$ and $\mathbf{\varphi}$ represent the structural displacement vector and the electric potential vector; ${\mathbf{M}}_{\mathbf{u}\mathbf{u}}$, ${\mathbf{C}}_{\mathbf{u}\mathbf{u}}$, ${\mathbf{K}}_{\mathbf{u}\mathbf{u}}$, ${\mathbf{K}}_{\mathbf{u}\mathbf{\varphi}}$ (${\mathbf{K}}_{\mathbf{\varphi}\mathbf{u}}$) and ${\mathbf{K}}_{\mathbf{\varphi}\mathbf{\varphi}}$ are the structural mass matrix, the damping matrix, the structural stiffness matrix, the piezoelectric coupling matrix, the dielectric stiffness matrix, respectively; ${\mathbf{F}}_{\mathbf{u}}$ and ${\mathbf{F}}_{\mathbf{\varphi}}$ are the structural load vector and the electric load vector, respectively.
The damping matrix ${\mathbf{C}}_{\mathbf{u}\mathbf{u}}$ is usually defined as a linear combination of the structural mass matrix ${\mathbf{M}}_{\mathbf{u}\mathbf{u}}$ and the structural stiffness matrix ${\mathbf{K}}_{\mathbf{u}\mathbf{u}}$ as follows:
where, the constants $\alpha $ and $\beta $ are the Rayleigh’s damping coefficients.
2.2. Ptype IL control
As a type of IL control, the Ptype IL control algorithm learns the tracking error from the previous iteration and uses an update rule to adjust the control signal in the current iteration to reduce the tracking error [36]. Fig. 1 demonstrates the block diagram of Ptype IL control. ${u}_{k}$ and ${y}_{k}$ are input signal and measured output signal at the $K$th iteration, respectively, and both of them are stored in memory when the system operates. The Ptype IL control evaluates the current performance of dynamic system based on the output error ${e}_{k}={y}_{d}{y}_{k}$, where ${y}_{d}$ is the desired output signal.
Fig. 1. Block diagram of Ptype IL control algorithm
The update rule of the Ptype IL control can be expressed as [37]:
where, $\mathrm{\Phi}$ is the learning gain. An iterative method computes successive approximations such that the output of the system approaches an appropriate value as time increase. However, the learning process should be accomplished within a limited period, over learning may lead to control spillover or system instability once it enters a ‘dangerous zone’ [10]. Therefore, the number of iterations should be limited to the predefined value so that the system knows when to stop the learning process.
2.3. Control mechanism
The piezoelectric sensor generates output electric potential when the structure is oscillating. The partitioned global piezoelectric FE equations of (1) can be easily uncoupled into the following independent equations for the sensor output electric potential:
and the structural displacement:
where, ${\mathbf{K}}^{\mathrm{*}}={\mathbf{K}}_{\mathbf{u}\mathbf{u}}{\mathbf{K}}_{\mathbf{u}\mathbf{\varphi}}{\mathbf{K}}_{\mathbf{\varphi}\mathbf{\varphi}}^{1}{\mathbf{K}}_{\mathbf{\varphi}\mathbf{u}}$.
Note that ${\mathbf{F}}_{\mathbf{\varphi}}$ is usually zero in sensor. Thus, the sensor output electric potential can be rewritten as:
In the application of vibration suppression, the desired output signal is always defined as zero. Considering the sensor output electric potential as feedback signal, the output error at time instant ${r}_{\mathrm{13,2}}$ is defined as:
The output error change at time instant ${r}_{\mathrm{13,4}}$ can be defined as:
According to the update rule of Ptype IL control in Eq. (3), the feedback gain at time instant $t$ can be given as:
The electric potential is amplified and fed back into the actuator. The input voltage to the actuator is expressed as:
where, $K$ is the feedback gain in Eq. (9), $\mathbf{\varphi}$ is the sensor output electric potential in Eq. (6).
The electric load vector can be defined as:
where, ${G}_{d}$ is electric load feedback control coefficient.
The feedback control force is defined as ${\mathbf{F}}_{\mathbf{a}}={\mathbf{K}}_{\mathbf{u}\mathbf{\varphi}}{\mathbf{K}}_{\mathbf{\varphi}\mathbf{\varphi}}^{1}{\mathbf{F}}_{\mathbf{\varphi}}$ [30], combining with the Eqs. (6), (10) and (11), ${\mathbf{F}}_{\mathbf{a}}$ can be rewritten as:
The feedback control force generated by actuator is used to suppress the vibration of piezoelectric smart structure. Substituting Eqs. (6), (10), (11) into Eq. (5), the active vibration control equations of piezoelectric smart structure can be expressed as:
3. Optimal fuzzy IL control design
The optimal fuzzy IL control system for vibration suppression of piezoelectric smart structures can be designed by applying MATLAB and ANSYS. For a piezoelectric smart structure with $j=\mathrm{1,2},\dots ,D$ piezoelectric actuatorsensor pairs, the optimal fuzzy IL control system is shown in Fig. 2, and each actuatorsensor pair is controlled independently. The Ptype IL control, the fuzzy logic control and the ABC algorithm has been circled by different line types, respectively. By using APDL approach, Ptype IL controller and fuzzy logic controller is incorporated into the ANSYS FE model to simulate the vibration control actions of the piezoelectric smart structure. The main program of ABC algorithm is operated in MATLAB.
In Fig. 2, the whole implementation of optimal fuzzy IL controller is presented clearly. In ANSYS FE model, the Sensor $l$ generates output electric potential ${\varphi}_{l}\left(t\right)$ in Eq. (6), when the piezoelectric smart structure is forced by external disturbance ${F}_{u}$. The output error of the Sensor $l$${e}_{l}\left(t\right)$ in Eq. (7) and output error change of the Sensor $l$$e{c}_{l}\left(t\right)$ in Eq. (8) act as input variables in fuzzy logic control, and the output variable is the learning gain ${\mathrm{\Phi}}_{l}\left(t\right)$ in Eq. (9). ${K}_{el}$ and ${K}_{ecl}$ denote the fuzzification parameters that convert the practical input values into linguistic levels, ${K}_{\mathrm{\Phi}l}$ is the defuzzification parameter which transforms the values of fuzzy output variables into practical output values. In this paper, it is assumed that the values of all fuzzy output variables are chosen from the unique fuzzy query table. For accelerating the learning speed of feedback gain ${K}_{l}\left(t\right)$ in Eq. (9), the learning gain ${\mathrm{\Phi}}_{l}\left(t\right)$ can be adjusted adaptively by fuzzy logic controller. ${G}_{dl}$ is electric load feedback control coefficient, where, $l=\mathrm{1,2},\dots ,N$, $N$ is the number of actuatorsensor pairs. The feedback control force ${F}_{a}$ in Eq. (12) generated by actuators is used to suppress the vibration of piezoelectric smart structure.
In MATLAB environment, the initial values of optimized parameters (including fuzzification parameters, defuzzification parameters and values in fuzzy query table) are generated randomly by using ABC algorithm, and these initial values are then delivered to the ANSYS FE model to update the current data. The vibration control actions of the piezoelectric smart structure begin to be simulated in ANSYS. As long as the training period has been reached, the value of objective function is saved and transmitted to the program in MATLAB to operate the fitness evaluation. The objective function of optimization problem is formulated based on the minimization in the sum of integral absolute output error of all sensors:
where, $T$ is the training period. The choice of training period should guarantee that control system instability will not happen after this specified time. The new set of optimized parameters will be memorized if its fitness value is better than that of the current one; otherwise, the current solution set is retained. This search process is repeated until the termination criterion is satisfied. Finally, the optimal configuration of the parameters for optimal fuzzy IL controller can be obtained. The detailed process of the fuzzy logic control and ABC algorithm has been designed as follow.
Fig. 2. The block diagram of optimal fuzzy IL control
3.1. Fuzzy logic control
The fuzzy logic controller designed in this paper involves three basic steps [38, 39]: fuzzification, fuzzy rule and fuzzy inference, defuzzification.
3.1.1. Fuzzification
All of input and output variables should be decided in this step and the fuzzy sets are constructed over all input and output variables. The sensor output electric potential acts as feedback signal, this paper considers the output error $e$ in Eq. (7) and its change $ec$ in Eq. (8) as input variables, and the output variable is the learning gain $\mathrm{\Phi}$ in Eq. (9). These input and output variables in the fuzzy set are represented by $E$, $EC$ and $\stackrel{~}{\mathrm{\Phi}}$, respectively. The ranges of practical output error $e$ and output error change $ec$ can be defined as $\left[\left{e}_{\mathrm{m}\mathrm{a}\mathrm{x}}\right,\left{e}_{\mathrm{m}\mathrm{a}\mathrm{x}}\right\right]$ and $\left[\lefte{c}_{\mathrm{m}\mathrm{a}\mathrm{x}}\right,\lefte{c}_{\mathrm{m}\mathrm{a}\mathrm{x}}\right\right]$. And the corresponding domain of ${C}_{44}=$ 23.3 GPa and ${C}_{66}=$ 23 GPa are defined as $\left[{E}_{\mathrm{m}\mathrm{a}\mathrm{x}},{E}_{\mathrm{m}\mathrm{a}\mathrm{x}}\right]$ and $\left[E{C}_{\mathrm{m}\mathrm{a}\mathrm{x}},E{C}_{\mathrm{m}\mathrm{a}\mathrm{x}}\right]$, respectively, then:
where, ${K}_{e}$ and ${K}_{ec}$ are fuzzification parameters, ${K}_{e}={E}_{\mathrm{m}\mathrm{a}\mathrm{x}}/\left{e}_{\mathrm{m}\mathrm{a}\mathrm{x}}\right$, ${K}_{ec}=E{C}_{\mathrm{m}\mathrm{a}\mathrm{x}}/\lefte{c}_{\mathrm{m}\mathrm{a}\mathrm{x}}\right$; ${e}_{\mathrm{m}\mathrm{a}\mathrm{x}}$ and $e{c}_{\mathrm{m}\mathrm{a}\mathrm{x}}$ are the maximum output error value and maximum output error change value.
A triangulartype membership function, as shown in Fig. 3, is employed to convert all input and output variables into linguistic variables. In this paper, membership functions of $E$, $EC$ and $\mathrm{\Phi}$ are defined in the same way. The values of membership functions are set in the range [0, 1]. There are seven different linguistic terms corresponding to linguistic variables, namely, NB (negative big), NM (negative middle), NS (negative small), ZE (zero), PS (positive small), PM (positive middle) and PB (positive big), respectively.
Fig. 3. Membership functions for ${\mathrm{\Phi}}_{3}=$ 0.0078, ${\mathrm{\Phi}}_{4}=$ 0.0148 and $\stackrel{~}{\mathrm{\Phi}}$
3.1.2. Fuzzy rule and fuzzy inference
The fuzzy rule is a significant factor that influences the performance of fuzzy logic controller in a large degree. Mamdani inference method is employed to generate the fuzzy rules in this paper, and the $w$th fuzzy rule can be defined as:
where, ${\mathrm{\Phi}}_{3}=$ 0.0078 and ${\mathrm{\Phi}}_{4}=$ 0.0148 represent the input fuzzy variables, $\stackrel{~}{\mathrm{\Phi}}$ is the output fuzzy variable; ${A}^{w}$ and ${B}^{w}$ represent the linguistic values of the input fuzzy variables, ${C}^{w}$ is the linguistic value of the output fuzzy variable. The 49 fuzzy rules are established for adjustment of learning gain, and listed in Table 1.
Table 1. Fuzzy rules
EC

E


NB

NM

NS

ZO

PS

PM

PB


NB

NB

NB

NM

NS

NS

ZO

ZO

NM

NB

NB

NM

NS

ZO

ZO

ZO

NS

NM

NM

NS

NS

ZO

ZO

PS

ZO

NS

NS

NS

ZO

PS

PS

PS

PS

NS

ZO

ZO

PS

PS

PM

PM

PM

ZO

ZO

ZO

PS

PM

PB

PB

PB

ZO

ZO

PS

PS

PM

PB

PB

The complicated fuzzy inference process inevitably causes timedelay, which may result in the degradation of control efficiency or even instability of control system [40]. An alternative approach to reduce time consumption in fuzzy inference is that establishing a fuzzy query table. It is given in Table 2. In the process of vibration control, the values of fuzzy output variables are chosen from the fuzzy query table directly, which can improve the realtime control performance of the system.
Table 2. The fuzzy query table
EC

E


–6

–5

–4

–3

–2

–1

0

1

2

3

4

5

6


–6

–5

–5

–5

–4

–4

–4

–4

–3

–2

–1

0

0

0

–5

–5

–4

–4

–4

–4

–3

–3

–3

–2

–1

0

0

0

–4

–5

–4

–4

–4

–4

–3

–2

–2

–2

–1

0

0

0

–3

–4

–4

–4

–3

–3

–3

–2

–1

–1

0

1

1

1

–2

–4

–4

–4

–3

–2

–2

–2

–1

0

1

2

2

2

–1

–4

–3

–3

–3

–2

–1

–1

0

1

1

2

3

3

0

–4

–3

–2

–2

–2

–1

0

1

2

2

2

3

4

1

–3

–3

–2

–1

–1

0

1

1

2

3

3

3

4

2

–2

–2

–2

–1

0

1

2

2

2

3

4

4

4

3

–1

–1

–1

0

1

1

2

3

3

3

4

4

4

4

0

0

0

1

2

2

2

3

4

4

4

4

5

5

0

0

0

1

2

3

3

3

4

4

4

4

5

6

0

0

0

1

2

3

4

4

4

4

5

5

5
